Enclosure System

The World’s Only Patented Self-Cleaning, Self-Wiping Outdoor PTZ Camera Enclosure

X|CLEAR ENCLOSURE SYSTEM TECHNOLOGY

CONSISTENTLY YIELDS CLEAR IMAGE QUALITY IN WET, RAINY, DIRTY AND HARSH ENVIRONMENTS

Protect your sensitive camera and surveillance equipment from the elements in our self-cleaning outdoor polycarbonate PTZ camera housings with our patented self-washing, self-wiping camera dome technology. At the heart of our X|Clear self-cleaning camera dome housing is our X|Smart power distribution platform with integrated 4 port 10/100Mbps network switch, heating element, redundant circulation fans, 12VDC, 24VDC and PoE accessory power ports – all remotely controllable via the X|Smart web interface. Our self-wiping self-cleaning camera dome housings provide clear image quality in wet, rainy, dirty and harsh environments. Learn more about X Stream Designs patented self-cleaning camera dome technology and the X|Clear outdoor camera housings below!

Engineered For All Conditions

Built To Withstand Severe Weather And Extreme Environmental Demands
Hot, Cold, Wet/Rainy, Salty Ocean Air, Grime, Bugs, Blowing Dust
Nearly Indestructible Polycarbonate Construction – No Rust Or Corrosion

Comprehensive And Customizable

Integrated Network Switch With PoE+ And 24VDC Passive PoE Ports
Remotely Controlled Accessory Power Ports – [2] 12VDC And [2] 24VDC
Integrate NVRs, Encoders, Routers And More With Built-In Accessory Rails
Extended Volume (EV) Option Adds 520in3 Of Integration-Ready Space

Remotely Monitor And Control

Remotely Monitor And Control The Enclosure Via The Web Or API
Manually Trigger Or Schedule Automated Dome Wash/Wipe Events
Power On/Off – 12VDC, 24VDC, PoE+ And 24VDC Passive PoE Ports
Monitor Internal And External Temps, Fluid Levels And Power Loads
Fine Tune And Adjust Internal Climate Settings
Customize Dome Wash And Wipe Settings

Economical, Practical, Smart

No More Ladders Or Awkward Fiberglass Dome Cleaning Devices
No Need To Schedule And Deploy Expensive Cleaning Crews
No More Staring at Poor Image Quality Caused By Dirty Dome Lenses
Eliminate The Risk Of Workplace Employee Injuries
Painless Installation With Wall Mount Bracket (Standard) Or Pole Mount Adapter
Power The Enclosure System Via AC Or DC

Integrate Virtually Any Camera

Compatible With Almost All Cameras With A Pan/Tilt Head Under 7 Inches in Diameter

30 Watt PoE+, 12VDC and 24 VDC Web Enabled Accessory Power Port

Sony logo

Samsung logo

Bosch logo

PTZ Optics logo

Canon logo

Panasonic logo

BirdDog logo

Axis Communications logo

Mobotix logo

IC Realtime Security Solutions logo

Hikvision logo

Hanwha logo

Dahua Technology logo

Avigilon logo

Arecont Vision logo

Bolin Technology logo

Experience the Clear Image Difference

Build Your Enclosure

Hardware: Durable. Robust. Convenient.

Nearly indestructible Polycarbonate Enclosure

Self-Cleaning Camera Dome

Rotates Against A Fixed Wiper Blade To Clear Dome Of Water Drops Or Residue
Reduces Risk Of Image-Obscuring Dome Scratches From Manual Cleaning

Polycarbonate Material

Non-Thermally Conductive
Durable And Protective
Doesn’t Rust And Will Not Corrode

X|Smart System Tray

Versatile Power Options, Integrated Networking, Climate Control And Remote Control Via Web Interface

Versatile Camera Integration

Fits Almost All Cameras With A Pan/Tilt Head Under 7” in Diameter
Easy Camera Height Adjustment With The Included 10-32 3/8″ Hex Standoffs
Integrated Camera Power Options:PoE+, 12VDC or 24VDC

Internal Fluid Reservoir

Holds 58oz Of Cleaning Fluid
Yields Up To 150 Washes (Based On Settings)

Intuitive Integration

Easily Integrate NVRs, Routers, Encoders And Other Peripherals
Accessory Mounting Rails For Easy Installation

Intelligent Cable Ingress

Reduce The Risk Of Water Intrusion With Cable Entry From Below

Stainless Steel Latches

Secure The Enclosure While Resisting Rust And Corrosion
Padlock-Compatible To Protect Your Equipment

Cleaning Fluid Spray Nozzle

Coats Dome Lens With Cleaning Fluid
Prior To Wiper Contact To Protect From
Scratches

Integrated Heat

20-Watt Integrated Heating Element
(Optional 50-Watt Upgrade)
Combats Moisture and Condensation
Keeps Components Within Operating Temperatures

Vertical Hinge

No-fuss access the enclosure interior for tank refills and component integration

Input Power Options

90-240VAC or 10-60VDC

Extra Volume (EV) Enclosure Upgrade

With an additional 520 cubic inches of integration-ready volume, the X|Clear-EV model enclosure system exposes the accessory mounting rails with even the tallest cameras providing the extra room and flexibility to integrate camera-complementing accessories including NVRs, Routers, Network Switches, Encoders, Media Converters, Power Supplies and more.

Extended Volume Lower Camera Tray
520 Cubic Inches Additional Integration Ready Volume
Exposes Accessory Mounting Rails Allowing for Up to Two Accessory Mounting Shelves

Simple And Secure Mounting

Durable Polycarbonate Wall Mount Bracket
(Optional Pole Mount Bracket Available)
Slide The Enclosure Onto The Bracket, Fasten
From The Inside With Four 1/4-20 x 3/4” Bolts
Industry-Standard 2” x 5.5” OC Hole Pattern

X|Smart System Tray

Dual Circulation Fans For Engineered Air Circulation
Remotely Controlled Power Inputs:
[2] 24 VDC Power Ports, [2] 12VDC Power Ports, [1] 30-Watt PoE+ Ethernet Port, [1] 24VDC Passive PoE Ethernet Port
Integrated Networking:
4 Port 10/100Mbps Ethernet Switch
Flexible Source Power:
120/240VAC Standard (10-60DC Optional)

Superior Air Circulation

Redundant 6,000 RPM 9.9 CFM Circulation Fans Push And Pull Air Throughout The Entire Enclosure System
Protects Equipment By Eliminating Hot Spots
Keeps Sensitive Components Within Their Specified Operating Temperatures

User Interface:
Simple. Intuitive. Accessible.

control from anywhere

Intuitively Designed For The End User – Ensure Pristine Image Quality With The Click Of A Mouse

Fluid Level Indicator

Remotely Monitor Cleaning Flulid Level

Clear Image Difference™ Controls

Manually Trigger Wash And Wipe Events
Schedule Wash And Wipe Events
View Previous And Upcoming Events
Manually Trigger Reservoir Fills
(Requires X|Aux-Reservoir Accessory)

Auxiliary Power Controls

30-Watt PoE+, 24VDC Passive PoE, 12VDC And 24VDC
Set Connected Devices To Power On Startup
Manually Power Devices On Or Off

Climate Control

Control The Enclosure’s Internal Temperature
Adjust Power Supply Fan Settings

At-A-Glance Information

See The Enclosure’s Local Date And Time
Review Power Status Of X|Accessories
Check Internal Temperature (Standard)
Check External Temperature With Optional X|EXT-TEMP Accessory
Review Current Power Input And Load

TAILOR YOUR CONTROL PANEL DISPLAY • CONFIGURE NETWORK AND POWER SETTINGS • REBOOT AND POWER CYCLE REMOTELY

Name Your Enclosure
Choose Which Information Is Displayed Based On Your Needs
Name Your Peripherals And Set Start-Up Power Options
Integrate The Camera Stream Directly Into The Web Interface
Customize Time, Date and Temperature Settings
Configure Network Settings
Review Power Usage and Temperature Graphs
Adjust Log In Credentials And Authentication Requirements
Reboot Or Shut Down The Enclosure System
Update System Firmware
All X|Accessories Are Seamlessly And Automatically Integrated Into The Web Interface

Specifications and Dimensions

Shipping Dimensions/Weight

X|CLEAR: 19”L x 15”W x 22”H – 20lbs
X|CLEAR-EV: 21”L x 16”W x 25.5”H – 22lbs

Input Source Power

120/240VAC Input Power (Standard)
10-60VDC Input Power (Optional)

Power Consumption

20 Watts With Typical PTZ Camera
75 Watts – Less Than 3 Seconds During Wash Event

Remotely Controlled Aux Power Ports

[2] – 12VDC Ports
[2] – 24VDC Ports
[1] – IEEE 802.3at 30-Watt PoE+ 10/100Mbps Ethernet Port
[1] – 24VDC Passive PoE Ethernet Port (Wireless Radios)

Enclosure Operating Temperatures

-20º to 145º F (-28º to 63º C)
Temperatures Vary Depending On Integrated Components. Check Operating Temperatures Of Integrated Cameras And Components As They May Vary
