X Stream Designs XRain Enclosure Product Logo

Enclosure System

X Stream Designs XRain Model Enclosure Open With Integrated PTZ Camera SE

The World’s Only Patented Self-Wiping, Self-Cleaning Outdoor Camera Enclosure System

X|RAIN TECHNOLOGY

THE INNOVATIVE POLYCARBONATE OUTDOOR CAMERA HOUSING WITH WIPER. PATENTED TECHNOLOGY THAT YIELDS CLEAR IMAGE QUALITY IN RAINY & WET WEATHER CONDITIONS

Protect your sensitive camera and surveillance equipment from the elements in our patented self wiping outdoor polycarbonate PTZ camera housings with wiper. Cameras tend to focus on raindrops and dirty dome lenses in backlight conditions. The self-wiping camera housing with wiper solves these issues removing the rain and water while simultaneously cleaning the dome lens. At the heart of our X|Rain self wiping camera housing with wiper is our X|Smart power distribution platform with integrated 4 port 10/100Mbps network switch, heating element, redundant circulation fans, 12VDC, 24VDC and PoE accessory power ports – all remotely controllable via the X|Smart web interface. Learn more about X Stream Designs patented self wiping camera housing with wiper and the technology below!

Engineered for Wet and Rainy Conditions

  • Wipe Away Image-Obscuring Water Drops In Wet And Rainy Weather
  • Built To Withstand Severe Weather And Extreme Environmental Demands
  • Recommended For Hot, Cold, Wet And Rainy Climates
  • Nearly Indestructible Polycarbonate Construction – No Rust Or Corrosion

Comprehensive and Customizable

  • Integrated Network Switch With PoE+ And 24VDC Passive PoE Ports
  • Remotely Controllable Accessory Power Ports – [2] 12VDC And [2] 24VDC
  • Integrate NVRs, Encoders, Routers And More With Built-In Accessory Rails
  • Extended Volume (EV) Option Adds 520in3 Of Integration-Ready Space

Remotely Monitor and Control

  • Remotely Monitor And Control The Enclosure Via The Web Or API
  • Manually Trigger or Schedule Automated Dome Wipe Events
  • Power On/Off – 12VDC, 24VDC, PoE+ And 24VDC Passive PoE Ports
  • Monitor Internal And External Temperatures And Power Loads
  • Fine Tune And Adjust Internal Climate And Dome Wiping Settings

Economical, Practical, Smart

  • Trigger Wipe Events To Clean The Dome Lens During Rainy Conditions
  • No More Staring at In Focus Rain Drops During Rainy Weather
  • Painless Installation With Standard Wall Mount Bracket Or Pole Mount Adapter
  • Power The Enclosure System via AC or DC

Integrate Virtually Any Camera

Compatible With Almost All Cameras With A Pan/Tilt Head Under 7 Inches in Diameter

30 Watt PoE+, 12VDC and 24 VDC Web Enabled Accessory Power Port

Experience The Clear Image Difference™

Build Your Enclosure

Hardware: Durable. Robust. Convenient.

Nearly indestructible Polycarbonate Enclosure

Self-Wiping Dome

  • Dome Rotates Against A Fixed Wiper Blade To Clear Water Drops
  • Reduces Risk Of Image-Obscuring Dome Scratches From Manual Cleaning

Polycarbonate Material

  • Non-Thermally Conducive
  • Durable And Protective
  • Doesn’t Rust And Will Not Corrode

X|Smart System Tray

  • Versatile Power Options, Integrated Networking, Climate Control And Remote Control Via Web Interface

Versatile Camera Integration

  • Fits Almost All Cameras With A Pan/Tilt Head Under 7” in Diameter
  • Easy Camera Height Adjustment With The Included 10-32 3/8″ Hex Standoffs
  • Integrated Camera Power Options:PoE+, 12VDC or 24VDC

Intuitive Integration

  • Easily Integrate NVRs, Routers, Encoders And Other Peripherals
  • Accessory Mounting Rails For Easy Installation

Intelligent Cable Ingress

  • Reduce The Risk Of Water Intrusion With Cable Entry From Below

Stainless Steel Latches

  • Secure The Enclosure While Resisting Rust And Corrosion
  • Padlock-Compatible ToProtect Your Equipment

Integrated Heat

  • 20 Watt Integrated Heat – Warms Enclosure (Optional 50W Upgrade)
  • Combats Moisture and Condensation
  • Keeps Components Within Operating Temperatures

Vertical Hinge

  • No-Fuss Access The Enclosure Interior For Maintenance And Component Integration

Input Power Options

  • Choose from 120/240VAC or 10-60VDC Input Power

Extra Volume (EV) Enclosure Upgrade

With an additional 520 cubic inches of integration-ready volume, the X|Rain-EV model enclosure system exposes the accessory mounting rails with even the tallest cameras providing the extra room and flexibility to integrate camera-complementing accessories including NVRs, Routers, Network Switches, Encoders, Media Converters, Power Supplies and more.

  • Extended Volume Lower Camera Tray
  • 520 Cubic Inches Additional Integration Ready Volume
  • Exposes Accessory Mounting Rails Allowing for Up to Two Accessory Mounting Shelves

Simple And Secure Mounting

x stream designs xrain climate controlled ptz camera enclosure wall mount
  • Durable Polycarbonate Wall Mount Bracket
    (Optional Pole Mount Bracket Available)
  • Slide The Enclosure Onto The Bracket, Fasten From The Inside With Four 1/4-20 x 3/4” Bolts
  • Industry-Standard 2” x 5.5” OC Hole Pattern

X|Smart System Tray

XSmart System Tray from X Series Model Enclosure
  • Dual Circulation Fans For Engineered Air Circulation
  • Remotely Controlled Power Inputs:
    [2] 24 VDC Power Ports, [2] 12VDC Power Ports,[1] 30 Watt PoE+ Ethernet Port, [1] 24VDC Passive PoE Ethernet Port
  • Integrated Networking:
    4 Port 10/100Mbps Ethernet Switch
  • Flexible Source Power:
    120/240VAC Standard (10-60DC Optional)

Superior Air Circulation

X Stream designs X|Rain EV outdoor climate controlled PTZ camera enclosure solution for rainy biomes
  • Redundant 6,000 RPM 9.9 CFM Circulation Fans Push And Pull Air Throughout The Entire Enclosure System
  • Protects Equipment By Eliminating Hot Spots
  • Keeps Sensitive Components Within Their Specified Operating TemperaturesKeeps Sensitive Components Within Their Specified Operating Temperatures

User Interface:
Simple. Intuitive. Accessible.

control from anywhere

Intuitively Designed For The End User – Ensure Pristine Image Quality With The Click Of A Mouse

x stream designs xrain gui no graphs

CLEAR IMAGE DIFFERENCE™ CONTROLS

  • Manually Trigger Wipe Events
  • Schedule Wipe Events
  • View Previous And Upcoming Events

AUXILIARY POWER CONTROLS

  • 30 Watt PoE+, 24VDC Passive PoE, 12VDC And 24VDC Power Ports
  • Set Connected Devices to Power On Startup
  • Manually Power Devices On Or Off

CLIMATE CONTROL

  • Control The Enclosure’s Internal Temperature
  • Adjust Power Supply Fan Settings

AT-A-GLANCE INFORMATION

  • See The Enclosure’s Local Date And Time
  • Review Power Status Of X|Accessories
  • Check Internal Temperature (Standard)
  • Check External Temperature With Optional X|EXT-TEMP Accessory
  • Review Current Power Input And Load

TAILOR YOUR CONTROL PANEL DISPLAY • CONFIGURE NETWORK AND POWER SETTINGS • REBOOT AND POWER CYCLE REMOTELY
  • Name Your Enclosure
  • Choose Which Information Is Displayed Based On Your Needs
  • Name Your Peripherals And Set Start-Up Power Options
  • Integrate The Camera Stream Directly Into The Web Interface
  • Customize Time, Date and Temperature Settings
  • Configure Network Settings
  • Review Power Usage and Temperature Graphs
  • Adjust Log In Credentials And Authentication Requirements
  • Reboot Or Shut Down The Enclosure System
  • Update System Firmware
  • All X|Accessories Are Seamlessly And Automatically Integrated Into The Web Interface

Specifications and Dimensions

SHIPPING DIMENSIONS / WEIGHT

  •  X|RAIN: 19”L x 15”W x 22”H – 20lbs
  • X|RAIN-EV: 21”L x 16”W x 25.5”H – 22lbs

INPUT SOURCE POWER

  • 120/240VAC Input Power (Standard)
    10-60VDC Input Power Optional

POWER CONSUMPTION

  • 20 Watts With Typical PTZ Camera
  • 40 Watts With Typical PTZ Camera, Heat On
  • 55 Watts – Less Than 3 Seconds During Wipe Event With Camera and Heat On

REMOTELY CONTROLLED AUX POWER PORTS

  • [2] – 12VDC Ports
  • [2] – 24VDC Ports
  • [1] – IEEE 802.3at 30Watt PoE+ 10/100Mbps Ethernet Port
  • [1] – 24VDC Passive PoE Ethernet Port (Wireless Radios)

ENCLOSURE OPERATING TEMPERATURES

  • -20º to 145º F (-28º to 63º C)
    Check Operating Temperatures Of Integrated Cameras And Components As They May Vary

REMOTE CLIMATE CONTROL

  • 20 Watts Integrated Heat (Standard)
  • 50W and  70W Heating Capacity (Optional)

ENCLOSURE MOUNTING

  • Wall Mount Bracket (Standard)
  • Pole Mount Bracket (Optional)

USER INTERFACE REQUIREMENTS

  • Network Connection Required
  • Compatible With All Modern Browsers
    Internet Explorer Not Recommended
  • Full API Documentation

Standard Dimensions

Extended Volume Dimensions

Design Your Perfect Enclosure

Tailor-Made To Fit Your Needs

Choose Your Camera

Compatible With Almost All Cameras With A Pan/Tilt Head Under 7 Inches in Diameter

Axis Communications logo Axis M5525-E PTZ Camera

M5525-E

Axis Communications logo Axis P5655-E PTZ Camera

P5655-E

Axis Communications logo Axis Q6075-E PTZ Camera

Q6075

Axis Communications logo Axis Q6128-E PTZ Camera

Q6128-E

Axis Communications logo Axis Q6155-E PTZ Camera

Q6155-E

Axis Communications logo Axis V5925 PTZ Camera

V5925

Bosch logo Bosch NDP 4502-Z12C PTZ Camera

Autodome IP 4000i

Bosch logo Bosch NDP 5502-Z30C PTZ Camera

Autodome IP 5000i

Bosch logo Bosch NDP 5512-Z30C PTZ Camera

Autodome IP Starlight 5000i

Bosch logo Bosch VG5 7230 CPT5 PTZ Camera

Autodome IP Starlight 7000HD

Bosch logo Bosch NDP 5502-Z30C PTZ Camera

Autodome IP Starlight 7000i

Axis Communications logo Axis V5838 4K UHD PTZ Camera

V5938

Bosch logo Bosch NDP 7602 Z30CT PTZ Camera

AUTODOME Inteox 7000i

Bosch logo Bosch NDP 5523 Z20C-P PTZ Camera

Autodome IP Starlight 5100i

Panasonic AW HE38HW PTZ Camera

AW-HE38H

Panasonic AW HN40HW HE40SW HE40HW PTZ Camera

AW-HE40H

Panasonic AW HN40HW HE40SW HE40HW PTZ Camera

AW-HE40S

Panasonic AW HE42W PTZ Camera

AW-HE42

Panasonic AW HN38H PTZ Camera

AW-HN38H

Panasonic AW HN40HW HE40SW HE40HW PTZ Camera

AW-HN40H

Panasonic AW UE100W PTZ Camera

AW-UE100

Panasonic AW UE4W PTZ Camera

AW-UE4

AW-UE70

AW-UN70

Sony BRC X400 4k Streaming Camera

BRC-X400

BirdDog logo

P100

BirdDog logo

P200

BirdDog logo

P400

BirdDog logo

P4K

PTZOptics NDI GY PTZ Camera

PT12X-NDI

PTZOptics PT SDI WH G2 PTZ Camera

PT12X-SDI-G2

PTZOptics PT12X USB WH G2 PTZ Camera

PT12X-USB-G2

PTZOptics NDI GY PTZ Camera

PT20X-NDI

PT20X-SDI-G2

PTZOptics PT20X USB WH PTZ Camera

PT20X-USB-G2

PTZOptics PT30X NDI WH PTZ Camera

PT30X-NDI

PTZOptics PT30X SDI WH G2 PTZ Camera

PT30X-SDI-G2

Sony SRG 300h HD PTZ Streaming Camera

SRG-300H

Sony SRG X120 White PTZ Camera

SRG-X120

Sony SRG X400 HD PTZ Streaming Camera

SRG-X400

WV-S6111

WV-S6130

WV-S6131

Choose Your Upgrades And Accessories

Don’t See A Component Listed? X Stream Designs Can Integrate Virtually Anything!

X Stream Designs, Inc. logo X Stream Designs - X-NVR - Intel Based Processor NVR With Solid State Hard Drive

X|NVR

X Stream Designs, Inc. logo X Stream Designs - X-20WH - 20 Watt Silicone Rubber Heating Element

X|20WH

X Stream Designs, Inc. logo X Stream Designs - X-DC-INPUT - Optional 10-60VDC Input Source Power Upgrade Accommodates 12, 24 and 48VDC Off-Grid Solar Systems

X|DC-Input

X Stream Designs, Inc. logo X Stream Designs - X|EXT-TEMP optional external temperature probe accessory for the X-Series enclosures

X|Ext-Temp

X Stream Designs, Inc. logo X Stream Designs - XSHELF - Optional Accessory Shelf Slides Into Accessory Rails

X|Shelf

X Stream Designs, Inc. logo X Stream Designs - X-HIGH-CFM - Optional High CFM Circulation Fans Move 32 Cubic Foot Per Minute

X|High-CFM

X Stream Designs, Inc. logo X Stream Designs - XPMB - Optional Pole Mount Bracket With Leveling Plate

X|PMB

X Stream Designs, Inc. logo X Stream Designs - X-IK-AXQ60 - Axis Q Series PTZ Camera Integration Kit

X|IK-AXQ60

Ubiquiti Networks logo Ubiquiti Edgeswitch ES-5XP Network Switch

Edgeswitch ES-5XP

X Stream Designs, Inc. logo X Stream Designs - X-IK-AXQ60 - Axis Q Series PTZ Camera Integration Kit

X|IK-BOSAD

Cradlepoint logo Cradlepoint IBR600 Cellular Router

IBR600C Series Router

X Stream Designs, Inc. logo X Stream Designs - X-INSULATE - Optional Laser Cut Open Cell Silicone Foam Provides Radiant Heat Shielding

X|Insulate

Cradlepoint logo Cradlepoint IBR200 Series Router

IBR200 Series Router

Ubiquiti Networks logo Ubiquiti NBE-5AC-13 Wireless Radio Pair

NBE-5AC-13 Radios (Pair)

Ubiquiti Networks logo Ubiquiti NBE-5AC-13 Wireless Radio Pair

NS-5AC-US Radios (Pair)

X Stream Designs, Inc. logo X Stream Designs - X-50WH - 20 Watt Silicone Rubber Heating Element

X|50WH

X Stream Designs, Inc. logo X Stream Designs - X-IP67-PMRJ45 - Panel Mount Non-Shielded IP67 RJ45 Input Jack With Cap and Cable Strain Relief

X|IP67-PMRJ45

X Stream Designs, Inc. logo X Stream Designs - X-IP67-PMRJ45 - Panel Mount Non-Shielded IP67 RJ45 Input Jack With Cap and Cable Strain Relief

X|IP67-SPMRJ45

X Stream Designs, Inc. logo X Stream Designs - XML-MIC - Mic Level Input Outdoor Omni-Directional Microphone With Non-Metalic Flex Conduit

X|ML-MIC

X Stream Designs, Inc. logo X Stream Designs - X-LLMI - 12VDC Microphone Pre-Amp / Interface with Adjustable Gain Control

X|LLMI

X Stream Designs, Inc. logo X Stream Designs - X-OR-SC5EE - Outdoor Rated Cat 5e Shielded Ethernet Cable With ESD Drain Wire Terminated with Shielded RJ45 Terminations

X|OR-SC5EE

X Stream Designs, Inc. logo X Stream Designs - X-RCMP-WS - Replacement Camera Mounting Plate with Stencil Guides

X|RCMP-WS

X Stream Designs, Inc. logo X Stream Designs - X-RGDL - Replacement Geared Dome Lens Kit for XClear and XRain Model Enclosures

X|RGDL

X Stream Designs, Inc. logo X Stream Designs - X-RPWMB - Replacement Polycarbonate Wall Mount Bracket and Stainless Steel Hardware

X|RPWMB

X Stream Designs, Inc. logo X Stream Designs - X-RSSL - Replacement Stainless Steel Latches Kit - Includes 2x Stainless Steel Latches & Associated Stainless Steel Hardware to Install the Latches

X|RSSL

X Stream Designs, Inc. logo X Stream Designs - X-SEPC-1 - 1 Foot Shielded Ethernet Patch Cable

X|SEPC-1

X Stream Designs, Inc. logo X Stream Designs - X-SEPC-2 - 2 Foot Shielded Ethernet Patch Cable

X|SEPC-2

X Stream Designs, Inc. logo X Stream Designs - X-SLPT - Optional Street Light Power Tap

X|SLPT

X Stream Designs, Inc. logo

X|SS-POLESTRAPS

X Stream Designs, Inc. logo X Stream Designs - X-STROBE - Strobe Warning Light

X|Strobe

X Stream Designs, Inc. logo X Stream Designs - XTSLM - Optional Tower Mounted Strobe Lights

X|TSLM

X Stream Designs, Inc. logo X Stream Designs - X-RWIPER-A - Replacement Wiper Blade Assembly for XClear and XRain Model Enclosures

X|RWiper-A

X Stream Designs, Inc. logo X Stream Designs - X-RWIPER-B - Replacement Wiper Blade for XClear and XRain Model Enclosures

X|RWiper-B

X Stream Designs, Inc. logo X Stream Designs - X-AC-PC - 16 AWG 3 Conductor SJOOW Outdoor Rated AC Power Cord with 15Amp 125V Three Prong Plug

X|AC-PC

X Stream Designs, Inc. logo X Stream Designs - X-RDRM - Replacement Dome Rotating Motor for XClear and XRain Model Enclosures

X|RDRM

Media Gallery

See the enclosure in action

XRain Self Wiping Camera Enclosure System Installed On Dumpling Mountain In Katmai National Park Alaska Overlooking Brooks Camp
XRain Self Wiping Camera Housing Installed On The Cape Tower Overlooking Polar Bears In Wapusk National Park In Churchill Manitoba Canada
XRain Self Wiping Camera Housing System Installed On The Tundra Buggy Lodge Overlooking Polar Bears In Wapusk National Park In Churchill Manitoba Canada
XRain Self Wiping Camera Enclosure System Installed At Critical Point With Orcalab Overlooking Resident Orcas In Johnstone Strait In British Columbia Canada
XRain Self Wiping Camera Enclosure System Installed At Brooks Falls In Katmai National Park Alaska Overlooking Brown Bears And The Great Salmon Feast
XRain Self Wiping Camera Enclosure System Installed On The Lower River Platform at Brooks Camp In Katmai National Park Alaska Overlooking a Brown Bear
XRain Self Wiping Camera Enclosure System Installed At Critical Point Overlooking Resident Orcas In Robson Bight Ecological Reserve In BC Canada
XRain Self Wiping Camera Enclosure System Installed At Cracroft Point Overlooking Resident Orcas In Johnstone Strait In British Columbia Canada
XRain Self Wiping Camera Enclosure System Installed At Orcalab On Hanson Island Orcalab Overlooking Resident Orcas In British Columbia Canada

Experience The Clear Image Difference™

Build Your Enclosure
X Stream Designs XRain Enclosure Product Logo

Enclosure System

Enclosure Image

The World’s Only Patented Self-Wiping, Self-Cleaning Outdoor Camera Enclosure System
